Razor Barbed Wire
时间:2017-09-30 15:52来源:www.razorwire-mesh.com 作者:Razor Wire Factory 点击:
次
Razor Blade Specification: Reference Number Blade Style Thickness Wire Dia Barb Length Barb Width Barb spacing BTO-10 0.50.05 2.50.1 101 131 261 BTO-12 0.50.05 2.50.1 121 151 261 BTO-18 0.50.05 2.50.1 181 151 331 BTO-22 0.50.05 2.50.1 221 1
|
Razor Blade Specification:
|
Reference Number
|
Blade Style
|
Thickness
|
Wire Dia
|
Barb
Length
|
Barb
Width
|
Barb
spacing
|
|
BTO-10
|
 |
0.5±0.05
|
2.5±0.1
|
10±1
|
13±1
|
26±1
|
|
BTO-12
|
 |
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
26±1
|
|
BTO-18
|
 |
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
33±1
|
|
BTO-22
|
 |
0.5±0.05
|
2.5±0.1
|
22±1
|
15±1
|
34±1
|
|
BTO-28
|
 |
0.5±0.05
|
2.5
|
28
|
15
|
45±1
|
|
BTO-30
|
 |
0.5±0.05
|
2.5
|
30
|
18
|
45±1
|
|
CBT-60
|
 |
0.6±0.05
|
2.5±0.1
|
60±2
|
32±1
|
100±2
|
|
CBT-65
|
 |
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
100±2
|
RAZOR BARBED WIRE Concertina (CBT);RAZOR BARBED WIRE Obstacle (BTO)
Standard materials are either galvanized or stainless steel.
Standard packages products are shown in the tables above, special specifications available on request.
RAZOR BARBED WIRE Specification:
|
Barbed Tape Wire Specification |
|
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
|
450mm |
33 |
7-8M |
CBT-60.65 |
Single coil |
|
500mm |
56 |
12-13M |
CBT-60.65 |
Single coil |
|
700mm |
56 |
13-14M |
CBT-60.65 |
Single coil |
|
960mm |
56 |
14-15M |
CBT-60.65 |
Single coil |
|
450mm |
56 |
8-9M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
500mm |
56 |
9-10M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
600mm |
56 |
10-11M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
600mm |
56 |
8-10M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
700mm |
56 |
10-12M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
800mm |
56 |
11-13M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
900mm |
56 |
12-14M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
960mm |
56 |
13-15M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
|
980mm |
56 |
14-16M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
